Model No: KL5055
58.5*21mm U8/U9 RFID UHF Flag tag
RFID UHF flag tag is complaint with EPC C1G2 (ISO18000-6C) standard, operating frequency is 860～960MHz (It can be used worldwide). By hanging and pasting, UHF flag tag can realize the anti-metal and anti-liquid purpose.
minimum order :
1 piece
Quantity :
Subscribe to our Newsletter
The folded part of the tag sticks out of the liquid container like a flag, and the attached antenna part uses the liquid container surface as part of the antenna structure to increase the performance of the tag. This kind of RFID anti liquid tag can be used for tracking management of bottle drinks, beverages, cosmetics, perfumes, blood bags, IT assets, metal objects, etc.
Wet Inlay/Label Size | 58.5*21mm |
Label Material | Coated Paper/PET/Fragile Paper |
Working Temp | -40~+85℃ |
Storage Temp | -40~+85℃ |
RFID Standard | ISO/IEC 18000-6C (EPC Gen2) |
Chip Type | NXP Ucode 8/9 |
EPC Memory | 128/96 bit |
TID Memory | 96 bit |
Read Range(2W ERP) | 5m |
Data Storage | > 10 years |
Re-write | 100,000 times |
Customization | Printing LOGO, Barcode, Serial number, Encoding, Designing,etc |
Application | Apparel management Logistics management Document management Assets management, etc  |
Note：
We can produce according to your quality, logo and colors requirements. Please contact us if you have any needs.
For large quantities, we provide custom services as below:
（1）.Custom mold
（2）. Custom color and logo printing.
（3）. Packaging design.
（4）.Custom packaging.
（4）.Product Pictures and FBA Shipping Photo.
（5）. Barcode printing for free.
We can produce according to your quality, logo and colors requirements. Please contact us if you have any needs.
For large quantities, we provide custom services as below:
（1）.Custom mold
（2）. Custom color and logo printing.
（3）. Packaging design.
（4）.Custom packaging.
（4）.Product Pictures and FBA Shipping Photo.
（5）. Barcode printing for free.
FAQ
Q: 1. Why Chooseus?
A: Excellent team—quick to solve problems, creative to design new items, latest RFID items are from us.
Big capacity—cost-effective and flexible to adjust production for volume and urgent orders.Strict QC factory—Voyantic Tagformance: 100% tags performance testing, control the sensitivity distribution within +/- 0.5 dBm
Q: 2. Can I get Free Samples?
A: The free sample will be offered all the time. But if you want customized samples,it would be charged.
Q: 3. OEM & ODM available?
A: We offer label design & selection, antenna design and manufacturing.
Q:4.How Long is your delivery time?
A:For small order in stock we will ship out within 1-2 working days. For bulk orders or customized orders,it will take about 5~10 working days according to order quantity.
Q:5.What is your MOQ?
A:It's usually 1000pcs depending on different products.
A: Excellent team—quick to solve problems, creative to design new items, latest RFID items are from us.
Big capacity—cost-effective and flexible to adjust production for volume and urgent orders.Strict QC factory—Voyantic Tagformance: 100% tags performance testing, control the sensitivity distribution within +/- 0.5 dBm
Q: 2. Can I get Free Samples?
A: The free sample will be offered all the time. But if you want customized samples,it would be charged.
Q: 3. OEM & ODM available?
A: We offer label design & selection, antenna design and manufacturing.
Q:4.How Long is your delivery time?
A:For small order in stock we will ship out within 1-2 working days. For bulk orders or customized orders,it will take about 5~10 working days according to order quantity.
Q:5.What is your MOQ?
A:It's usually 1000pcs depending on different products.
