Model No: KL9020
84*1mm Alien Higgs-9 RFID UHF Spring Tire Tag
This RFID spring tire tag is designed for embedding in the tire mould prior to the manufacture and curing of the tire. The tag survives the high temperatures encountered in the tire curing process and is robust enough to remain operational throughout the operating life of the tire.
minimum order :
1 piece
Quantity :
Subscribe to our Newsletter
This UHF tire tag is developed to be embedded within the tire during the manufacturing process, it will last the lifetime of the tire. With unique identification number can be tracked to prevent theft and cloning. UHF spring tire tag also can be embedded into other items in producing process,such as trunk,box,etc. Its advantage is small size, resist at least 200℃,etc.
Model | KL9020 |
Material | Steel wire |
Color | Green |
Dimensions | 84x1mm/50x1mm |
Weight | 0.2g |
Working Temp | -40~+85℃ |
Storage Temp | -40~+200℃ |
IP Code | IP65 |
RFID Standard | EPC C1G2 (ISO18000-6C) |
Chip Type | Alien Higgs-3/Higgs-9 |
EPC Memory | 96/96(496) bits |
User Memory | 512/688 bits |
Read Range(2W ERP) | 2.4m |
Data Storage | > 10 years |
Re-write | 100,000 times |
Customization | Encoding,Designing etc |
Package | 100pcs/bag |
Application | Tire factory control Tire asset tracking Automobile factory tire tracking Logistic vehicle management,etc.  |
